A709 Grade 50,A709Gr50T

A709 Grade 50,A709Gr50,A709Gr50 steel plate is a kind of low alloy structural steel which is for building bridges in normal constructions.For a better weathering resistance,generally steel plate A709 Grade 50W is better used for outside situiations.When rolling these steel materials A709 Grade 50,for each reduction of 0.01% below the specified carbon maximum,an increase of 0.06 manganese above the specified maximum will be permitted up till maximum of 1.35%.Xinsteel’s engineers suggest customer choose low temperature impacting test for steel plates A709 grade 50 at zero centigree,because these steel plates A709Gr50 normally used in this temperature.

Technical Requirements & Additional Services:
♦ High tension test
♦ Low temperature impacting test
♦ Simulated post-welded heat treatment (PWHT)
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ When cooper steel is specified for A709Gr50,the content Cu≥0.20%
♦ Shot blasting and Painting,Cutting and welding as per end user’s demands

►Mechnical property for A709Gr50 steel plate:

Yield strength (≥Mpa)	Tensile strength (≥Mpa)	Elongation in ≥,%
345	450	200mm	50mm
		18	21

►Chemical composition for A709Gr50 steel plate (Heat Analysis Max%)

Main chemical elements composition of A709Gr50 steel plate
Thickness(mm)	C	Si	Mn	P	S	Cu (Min)
T≤10	0.23	0.40	0.50-1.35	0.04	0.05	0.20
10<T≤40			0.80-1.35
40<T		0.15-0.40
