Corten B Welded Pipe

  • Steel Standard: CORTEN / YB/T 4112
  • Welding Type: ERW or LSAW
  • Wall Thickness: 0.4mm--80mm
  • Diameter: 3mm--2000mm
  • Length: 500mm--18000mm
  • Similar Product Name: Welded steel pipes,Corrosion resistance steel tubes,Electric-Welded steel tubes,LSAW steel pipe
(※ Click this button to inquiry)
■ Overview
Xinsteel can do corten b welded pipe with maximum diameter 2000mm,these corten b steel pipe can stand atmospheric corrosion with high Cr and Cu elements contains.If need Corten b welded pipe and Corten A welded pipe urgently,please contact Xinsteel freely.
■ Full Data
Technical Requirements & Additional Services for Corten B welded steel pipe:
♦ Atmospheric corrosion resistance for these pipes in Corten specification shall be comply to Guide G101.
♦ Hydrostatic test or Nondestructive electric test.
♦ Mill test certificate with EN 10204 TYPE 3.1 OR 3.2.
♦ CNC Cutting for Corten B seamless pipe according to customers'drawing.
♦ Surface Protection:Black,Varnish,Coating with shop prime,Bevelled end connection,Pipe Caps.

■ Techicals

Mechnical property for Corten B welded pipe:


Thickness(mm) Yield strength (Mpa) Min. Tensile strength (Mpa) Min. Elongation in ≥,%
T≤16 355 470-630 20
16<T 345


Chemical composition for Corten B welded pipe (Heat Analysis Max%)


Main chemical elements composition of Corten B
C Si Mn P S Cu Ni V Cr
0.16 0.30-0.50 0.80-1.25 0.030 0.030 0.25-0.40 0.40 0.02-0.10 0.40-0.65
