■ Overview
HOT ROLLED STAINLESS PLATE A240 347H shall be heated to temperature above 1040 ℃ (1900 ℉）when producing,and then quenched in water or rapidly cooled by other means at a rate sufficient to prevent reprecipitation of carbides,as demonstrable by the capability of passing the test for resistance to intergranular corrosion specified in 18.2.
■ Full Data
Technical Requirements & Additional Services for HOT ROLLED STAINLESS PLATE A240 347H:
♦ Ultrasonic examination comply to A578/A578M A577/A577M A435/A435M
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ PMI test report,Cutting and welding as per end user’s demands
♦ Packing with water-resistance paper and Non-fumigation wooden crates
♦ No.1 Surface with solid solution and pickling
♦ Ultrasonic examination comply to A578/A578M A577/A577M A435/A435M
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ PMI test report,Cutting and welding as per end user’s demands
♦ Packing with water-resistance paper and Non-fumigation wooden crates
♦ No.1 Surface with solid solution and pickling
■ Techicals
►Mechnical property for Stainless steel sheet A240 347H
|
HOT ROLLED STAINLESS PLATE A240 347H |
||||
|
Yield strength (≥Mpa) |
Tensile strength (≥Mpa) |
Elogation in 50mm min. % |
Hardness, Max |
|
|
Brinell HBW |
Rockwell HRBW |
|||
|
205 |
515 |
40 |
201 |
92 |
►Chemical composition for Stainless steel sheet A240 347H (Heat Analysis Max%)
|
Main chemical elements composition of HOT ROLLED STAINLESS PLATE A240 347H |
|||||
|
C |
Mn |
P |
S |
Si |
Cr |
|
0.04-0.10 |
2.00 |
0.045 |
0.030 |
0.75 |
17.0-19.0 |
|
Ni |
Mo |
N |
Cb |
Al |
Ti |
|
9.0-13.0 |
- |
- |
8*C-1.0 |
- |
- |
